For providing a higher upgradability, MSI's AM3 mainboards also support the AM3+ multi-core processors. For the innovative 32 nm process, AMD AM3+ multi-core processors deliver not only higher power efficiency but electrical specifications. Besides, AMD AM3+ multi-core processors support Turbo Core 2.0 which can promote the range of overclocking, and then help the customer get higher performance.
OC Genie, MSI Active Phase Switching (APS), Auto OC Genie, MSI Winki 3, MSI Solid Capacitors on PWM, Super Charger, AMD Hybrid CrossFireX technology support
Onboard LEDs Header
Yes
Power Supply Supported
EPS12V
Multi GPU Supported
CrossFire
Memory Speed Supported
1.33 GHz; 1.07 GHz; 800 MHz
Max Bus Speed
2600 MHz
Certifications & Standards
FCC; CE
Compatible Processors
Sempron, Phenom II X3, Athlon II X2, Phenom II X2, Athlon II X4, Athlon II X3, Phenom II X4, Phenom II X6, FX
Number of Network (RJ-45) Ports
1
Number of DVI Outputs
1
Internal Interfaces
4 x USB 2.0 - header ¦ 1 x serial - header ¦ 1 x SPDIF out - header ¦ 1 x audio - header
Registered or Buffered
Unbuffered
Audio Line In
Yes
Storage Interfaces
AMD SB710 : SATA-300 -connectors: 6 x 7pin Serial ATA - 6 devices - RAID 0 / RAID 1 / RAID 10 / JBOD
Number of PCI Express x16 Slots
1
Total Processor Supported
1
Total Number of PCI Express Slots
2
64-bit Processing
Yes
Bus Clock
1333 MHz, 1066 MHz, 800 MHz
VGA
Yes
Max Processors Qty
1
RAID Supported
Yes
brand name
MSI
Audio Channels
7.1
Network Controller
Realtek RTL8111E
Processor Technology
HyperTransport 3.0 Technology
Number of USB 2.0 Ports
6
Buttons & Keys
CMOS Clear; OC Genie
PS/2 Port
Yes
DVI
Yes
Memory Form Factor
DIMM
Processor Socket
Socket AM3+
Chipset Model
760G
Sound Controller Manufacturer
Realtek
Onboard Video
No
PCI Express Standard
PCI Express 2.0
Number of PCI Slots
1
Total Number of Onboard USB Ports
2
Power Connectors
4-pin ATX12V connector, 24-pin main power connector
RAID Levels
0; 1; 1+0; JBOD
Processor Supported
Athlon II X3; Athlon II X4; Athlon II X2; Athlon II; Phenom II X3; Phenom II X4; Phenom II X2; Phenom II X6; Sempron; Phenom II
